3 To 1 3.2mm Red Shrink Wrap Tubing 110C 110C Flexible Heat Shrink Tubing

Product Categories
Changzhou Longchuang Insulating Material Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

3 To 1 3.2mm Red Shrink Wrap Tubing 110C 110C Flexible Heat Shrink Tubing

  • 1
  • 2

Brand Name : Long

Model Number : SBRS-(3X)GLW

Certification : ISO

Place of Origin : China

MOQ : 10m

Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram

Supply Ability : 500000meter per day

Delivery Time : 1-10days

Packaging Details : Roll/Carton

Material : PE

Colour : Black

Feature : Flexible

Wall Thickness : Thick Adhesive

Shrink Ratio : 3:1

Min shrink temperature : 110

Total Wall Thickness mm : 0.90±0.30

Adhesive Thickness mm : 0.45±0.20

Contact Now

1/8 3.2mm Red Flexible, Thick Adhesive-Lined Dual Wall Heat Shrink Tubing

Flexible, Thick Adhesive-Lined Dual Wall Heat-ShrinkTubing is manufactured by co-extrusion of polyolefin and hot-melt adhesive. Designed to provide both insulation and sealing for protected articles, Used to protect bundles wires and metal tubes against water and moisture.

Features

Low longitudinal shrinkage

Thick adhesive liner bonding to a wide variety of plastics

ubber and metals forms an effective barrier against fluids

Flexible

Continuous operating temperature:-45°C-125°C

Min shrinktemperature:110°C

Shrink ratio: 3:1

Dimensions

Inch mm Internal Diameter mm Internal Diameter mm Total Wall Thickness mm

Adhesive

Thickness mm

 Spool Length M/spool
1/8 3.2 3.2 1.0 0.90±0.30 0.45±0.20 200
3/16 4.8 4.8 1.6 1.20±0.30 0.55±0.20 100
1/4 6.4 6.4 2.2 1.25±0.30 0.55±0.20 100
5/16 7.9 7.9 2.7 1.35±0.30 0.65±0.20 100
3/8 9.5 9.5 3.2 1.35±0.30 0.65±0.20 50
1/2 12.7 12.7 4.2 1.55±0.40 0.75±0.20 1.22OR25M/Roll
5/8 15.0 15.0 5.2 1.65±0.40 0.75±0.20 1.22OR25M/Roll
3/4 19.1 19.1 6.3 1.90±0.40 0.85±0.20 1.22OR25M/Roll
1 25.4 25.4 8.5 2.00±0.40 0.90±0.20 1.22OR25M/Roll
5/4 30.0 30.0 10.2 2.05±0.40 0.90±0.20 1.22OR25M/R0II
1-1/2 38.1 38.1 13.5 2.35±0.40 1.05±0.20 1.22OR25M/R0II

Technical Data

I Property Test Method Standard Typical Performance I
Tensile Strength(MPa) ASTM D2671 >10.4 11
Elongation(%) ASTM D2671 >300 450
Tensile Strength after aging (MPa) UI224 158°CX168hr N7.3 8.5
Elongation after aging(%) UI224 158°CX168hr N200 350
Dieletric strength(kV/mm) IEC 60243 315 17.5
Volume resistivity(n.cm) IEC 60093 >1X1014 2.5X1014

Adhesive

Property Test Method Standard I
Water Absorption ASTM D570 v0.2%
Sofening Point(°C) ASTM E28 90±5
Strength of pearing(PE) ASTM D 1000 120N/25mm
Strength of pearing(AL) ASTM D 1000 80N/25mm
